What Is The Function of The China Filter Press in The Factory?

We're filter press supplier in china,Filter press is a widely used mechanical equipment in industrial production, especially in fields such as sewage treatment, chemical industry, metallurgy, and environmental protection. In factories, filter presses are mainly used for solid-liquid separation, which separates solid substances from liquid and solid mixtures. This article will provide a detailed introduction to the use and working principle of filter presses in factories, in order to help readers better understand this equipment.

1、 The purpose of filter press

Filter presses are mainly used in the following fields:

1. Sewage treatment: In the field of sewage treatment, filter presses are mainly used for sludge dewatering. The sludge treated by the biological reaction tank and sedimentation tank is transported through pipelines to the filter press for dewatering. The filter press applies pressure to squeeze out the water in the sludge, thereby achieving dewatering of the sludge. The cement cake can be further processed or utilized.mining filter press machine.

2. Chemical industry: In the chemical industry, filter presses are mainly used for solid-liquid separation. For example, in the production of chemical products such as sulfuric acid and fertilizers, it is necessary to separate solid substances from liquids in the raw materials. At this time, a filter press can be used for separation.

3. Metallurgy: In the field of metallurgy, filter presses are mainly used for solid-liquid separation of slurry. By using a filter press, useful minerals and solid materials such as waste rocks in the slurry can be separated, improving the utilization rate of minerals.

4. Environmental Protection: In addition to the above-mentioned fields, filter presses are also widely used in the field of environmental protection. For example, in the treatment of industrial wastewater, urban sewage, etc., a filter press can be used for solid-liquid separation to ensure that the treated water quality meets discharge standards.

2、 Working principle of filter press

The filter press is mainly composed of a feed pump, filter press cloth,a filter screen, a clamping mechanism, and a hydraulic system. Its working principle is as follows:

1. The feed pump transports the mixture of liquid and solid to the filter screen of the filter press.

The function of a filter is to trap solid substances on its surface, while liquids flow out through the filter. At this point, the solid material is compressed on the surface of the filter to form a filter press cake.

3. The compression mechanism compresses the plate frames on both sides of the filter chamber to generate a certain amount of pressure. As time goes by, the pressure gradually increases, causing the water in the filter cake to be squeezed out.

4. The hydraulic system is the power source of the filter press, which drives the movement of the piston rod and plate frame through hydraulic oil to achieve functions such as filtration and compression.

When the preset filtering time or pressure is reached, the filter press automatically unloads and releases the plate frames on both sides of the filter chamber. Subsequently, the filter cake on the filter screen is scraped off by a scraper and discharged, completing the entire filtration process.

3、 Advantages of filter press

1. High separation efficiency: The filter press adopts high-pressure filtration technology, which can complete the separation of a large amount of solid-liquid mixture in a short time.

2. Energy saving and environmental protection: Compared with traditional separation methods such as sedimentation tanks and centrifuges, filter presses have lower energy consumption during operation and produce less sludge, which is beneficial for environmental protection.

3. High degree of automation: Most modern filter presses use intelligent control systems, which can achieve functions such as automatic feeding, automatic control of pressure and time, reducing manual operation and improving production efficiency.

4. Wide application range: Due to its high efficiency, energy saving, and environmental protection characteristics, filter presses have broad application prospects in various fields.

As an efficient and energy-saving solid-liquid separation equipment, filter press is widely used in factories. Its working principle is mainly to apply pressure to trap solid substances in the mixture of liquid and solid on the filter screen, forming a filter cake, while the liquid flows out through the filter screen. After a period of time, the clamping mechanism is released, and the scraper scrapes off the filter cake and discharges it, completing the entire filtration process. Filter presses play an important role in fields such as sewage treatment, chemical engineering, metallurgy, and environmental protection. With the continuous advancement of technology and the increasing demand for applications, the performance and functionality of filter presses will be further improved and perfected in the future.
